Brand Name : WS
Model Number : G5025
Place of Origin : Jiangsu, China (Mainland)
MOQ : 1 Set
Price : USD 1000.00-2800.00/set
Payment Terms : L/C, T/T, Western Union
Supply Ability : 300 Set/Sets per Month
Delivery Time : 30 working days
Packaging Details : Wooden box
Condition : New
Use : Metal cutting
Style : Horizontal
Voltage : 220V/380V/415V
Power : 1500/750w
Dimension(L*W*H) : 1540x700x1050mm
Certification : CE Certificate
Warranty : 1 Year
Cutting meterial : Metal Stainless Steel Carbon Steel Aluminum
Weight : 341/394kg
Blade size(mm) : 2725x27x0.9
The bow swivel degree : -45°- +60°
Blade speed(m/min) : 72/36
Specifications
For high precision metal cutting, is the ideal equipment for the industrial and mining enterprises and small workshops, use is very extensive.
Features
1.adjustable horizontal/vertical metalworking band saw
2.has a vise that swivels up to 45 degree
Usage
1, medical equipment, automatic control equipment, electrical appliances sound equipment, security monitoring equipment;
2, heater, atomizer, outdoor lighting project;
3, broadcasting system, the solar wind, electronic communications, etc.
Note
Specifications is for your reference. Owing to our continuous improvement of the machine, any changes of the machines and parts may be made without obligation on notice / should not be advised separately. Please check with us before order if there are strict requirements for the parameters.
Technical parameters
Model | G5025 |
Description | 10"metal band saw |
Motor(W) | 1500/750(380V) |
Blade size(mm) | 2725×27×0.9 |
Blade speed(m/min) | 72/36 |
The bow swivel degree | -45°- +60° |
Cutting capacity at 90° | 250mm 240×240mm 310×210mm |
Cutting capacity at 45° | 200mm 180×180mm 200×140mm |
Cutting capacity at 60° | 120mm 95×95mm 120×95mm |
Cutting capacity at 45°(L) | 150mm 150×150mm 170×90mm |
N.W./G.W.(kgs) | 341/394 |
Packing size(mm) | 1540×700×1050(body) 1100×760×180(stand) |
20' | 22pcs |
Product Details
Packing & Shipping
FAQ
What is your minimum order ?
Answer: 1 Set.
1. Payment Terms
T/T, L/C at sight are acceptable by us.
2. Price Terms
It is up to your requirement. EX-WORS, FOB, CIF, CFR and so on are acceptable by us.
3. Delivery Time
15-30 Days from our accountant confirm your deposit payment.
4. Shipment Condition
We will arrange the machine production from our accountant confirm your deposit payment. The deposit is 30% of the contract.
The balance should be paid up before loading machines.
5. Warranty
1 year quality guaranty for the main spare parts, not include quick-wears parts, like blade, punch, die and so on. If the parts of machines have problems, which are caused by its own quality, we will provide the accessories for free.
